WY80 Pressure Transducer

The WY80 Pressure Transducer is a diffused silicon pressure sensor specifically designed for pressure measurement in oil drilling operations and other demanding industrial environments.

Built with a high-performance diffused silicon sensing element, the WY80 delivers stable pressure measurement, excellent reliability, and dependable performance under challenging operating conditions.

What Is a Diffused Silicon Pressure Transducer?

A diffused silicon pressure transducer converts pressure into an electrical signal using a micromachined silicon sensing element.

When pressure is applied to the silicon diaphragm, the resistance of the integrated piezoresistive bridge changes proportionally. The internal electronics amplify and compensate this signal to produce an accurate pressure output.

Diffused silicon technology is widely recognized for its:

• High sensitivity

• Excellent measurement accuracy

• Good long-term stability

• Fast response

• Reliable industrial performance

Key Features

Diffused Silicon Sensing Technology

The WY80 utilizes a precision diffused silicon sensing element that provides:

• Stable pressure measurement

• High sensitivity

• Excellent repeatability

• Reliable long-term performance

Designed for Oil Drilling Applications

The WY80 is engineered primarily for pressure monitoring in oil drilling operations where reliable measurement is essential for safe and efficient equipment operation.

Typical applications include:

• Oil drilling systems

• Downhole pressure monitoring

• Oilfield equipment

• Pressure testing systems

• Industrial process monitoring

Pressure Measurement Options

The WY80 can be configured for different measurement references depending on application requirements:

• Gauge Pressure

• Absolute Pressure

Customized pressure ranges may also be available upon request.

Technical Specifications

Note: Pressure range, output signal, electrical connection, and process connection may be customized according to project requirements.

Typical Applications

The WY80 Pressure Transducer is suitable for demanding pressure measurement applications, including:

• Oil Drilling Equipment

• Oilfield Pressure Monitoring

• Drilling Fluid Systems

• Hydraulic Equipment

• Industrial Pressure Testing

• Process Automation

• OEM Equipment

Important Usage Considerations

Single-Use Design

The WY80 is designed for single-use applications.

After initial deployment, sensor performance and structural integrity should not be assumed for reuse. For safety and measurement reliability, the transducer should be replaced after its intended service cycle.

Media Compatibility

Before installation, users should verify that the process medium is compatible with the sensor's wetted materials.

For drilling fluids or chemically aggressive media, consult the manufacturer to confirm material compatibility and corrosion resistance.

Why Choose the WY80 Pressure Transducer?

The WY80 offers several advantages for specialized industrial applications:

• High-performance diffused silicon sensing technology

• Stable and accurate pressure measurement

• Fast sensor response

• Reliable operation in demanding environments

• Suitable for oil drilling pressure monitoring

• Available in gauge or absolute pressure configurations
