Digital Display Temperature and Humidity Sensor NK210 Series

Brand：ZANKE
Model：
Description：Digital Display Temperature and Humidity Sensor NK210 SeriesProduct Overvie
Online Consultation

Digital Display Temperature and Humidity Sensor NK210 Series

Product Overview

The NK210 series intelligent temperature and humidity products are high-precision, stable, and long-lasting, suitable for applications in various scenarios. They can adopt split-type probes or integrated probes and are equipped with mounting brackets for easy wall-mounted installation. This series of products includes two wired output solutions: 4-20mA current (HT-A) and RS485 (HT-R). It is equipped with an LCD display, which can display the current temperature and humidity values while transmitting data remotely. At the same time, this series of temperature and humidity products also includes intelligent terminals with GPRS/LORA/NB-iot wireless output, and the output protocol supports UDP/TCP/MQTT/COAP protocol modes.

Product Applications

It is applicable to scenarios that require temperature and humidity monitoring, such as pump rooms, equipment rooms, factory workshops, exhibition halls, etc.

Product Features

Optional 4-20mA/RS485 wired output modes
Provide customized development of protocol messages and interfaces
Optional GPRS/LORA/NB-iot wireless output (for NK210 series)
Optional split-type probe or integrated structure
High precision: temperature accuracy is better than ±0.2°C, humidity accuracy is better than ±3%RH
Compact in shape, wall-mounted design, easy to install

Technical Parameters

Model	TH210-A	TH120-R	TH120-G/L/N
Output Signal	4-20mA	RS485	GPRS/LoRA/NB-iot
Protocol Type	-	ModbusRTU	UDP/TCP/MQTT/CoAP
Supply Voltage	9-28VDC	-	-
Humidity Measurement Range	0-100%RH	-	-
Temperature Measurement Range	For NK210 series	-	-
Humidity Accuracy	±3%RH (5-90%RH)	-	-
Temperature Accuracy	±0.2°C (at 25°C)	-	-
Resolution	Temperature: 0.1°C; Humidity: 0.1%RH	-	-
Long-term Stability (Temperature)	<0.2°C/year	-	-
Long-term Stability (Humidity)	<0.5%RH/year	-	-
Installation Method	Wall-mounted	-	-
Response Time	Temperature: 5s; Humidity: 8s 1/e (63%)	-	-
Probe Installation Method	Integrated/split-type (the length of split-type cable can be customized)	-	-

Selection Table

NK210-	-	P2	-	TS1	L1	Detailed Description
NK210	-	-	-	-	-	Digital display temperature and humidity sensor
	A	-	-	-	-	Signal output: 4...20mA
R	-	-	-	-	-	Signal output: RS485
G	-	-	-	-	-	Signal output: GPRS
LR	-	-	-	-	-	Signal output: LORA
NB	-	-	-	-	-	Signal output: NB-iot
	P2	-	-	-	-	Supply voltage: 9-28VDC
	-	-	-	-	-	Shanghai Zanke NK210 series
	-	-	-	-	-	Accuracy: Temperature: ±0.3°C; Humidity: ±3%RH
	-	-	TS1	-	-	Temperature and humidity range: (-20~80°C) (0~100%RH)
	-	-	TS2	-	-	Temperature and humidity range: (-20~120°C) (0~100%RH)
	-	-	-	-	-	Customizable range
	-	-	-	LO	-	Probe type: Integrated probe
	-	-	-	L1	-	Probe type: Probe cable 1m
	-	-	-	L3	-	Probe type: Probe cable 3m
	-	-	-	L5	-	Probe type: Probe cable 5m

Wholesale of Digital Display Temperature and Humidity Sensor NK210 Series

Shanghai Zanke is a wholesale manufacturer of the digital display temperature and humidity sensor NK210 series. At this stage, the main products of Shanghai Zanke Company include flow switches, pressure switches, temperature switches, electromagnetic flowmeters, vortex flowmeters, turbine flowmeters, ultrasonic flowmeters, material (liquid) level flowmeters and other instruments. Application industries: petroleum chemical industry, natural gas, machinery, electric power, metallurgy, building materials, food and pharmaceutical manufacturing, agriculture, environmental protection, etc. (Our company can customize instrument specifications according to users' special requirements and on-site working conditions, and provide installation and commissioning services.)

Well, that's all for today's introduction to the working principle, application fields, characteristics, installation requirements, use and maintenance of the digital display temperature and humidity sensor NK210 series. If you have any other questions, please feel free to contact us, and we will reply to you as soon as possible after receiving your inquiry.
