Temperature Sensor NM140 Series

Product Overview

The NM140 is a temperature transmitter with a wide measurement range. It utilizes thermocouples or PT100 thermal resistors for temperature measurement. The signal is processed by the rear processing circuit and converted into a standard industrial electrical signal for output. The all-metal housing design allows this series of products to be used in various industrial occasions. HART output is optional. The electronic head part can be rotated, enabling users to adjust the cable outlet direction as required.

Product Features

• Universal product

• User-definable measurement range from -200 to 1800°C

• 4...20mA output

• Optional HART protocol

• Multiple process connections available

• Optional 4-digit LED/LCD digital display

• All-metal housing

Product Applications

• Circulating water/cooling water systems

• Iron and steel industry

• Oil and gas industry

• Machinery manufacturing

• Water treatment

• Glass industry

Technical Parameters

• Power supply voltage: 10...30Vdc

• Current consumption: Consistent with the output signal current (4...20mA)

• Output type: 2-wire current-type analog output

• Load RA (ohm): RA ≤ (Us - 10)V / 0.02A

• Linearity: ≤ ±0.5% of full scale

• Sensor: PT100 Class A (PT1000 can be customized)

• Measurement range: -200...1800°C (user-definable within this range)

• Ambient temperature: -20...80°C

• Storage temperature: -30...100°C

• Housing: Die-cast aluminum

• Medium contact part: 316 stainless steel

• Protection class: IP65

• Outlet mode: Terminal wiring

• Accuracy: ≤ ±0.2% of full scale

Wiring Diagram

Connection Schematic Diagram

NM140 Series

2-wire Type

1 24VDC

2

3

Terminal Wiring

Selection Table

Wholesale of Temperature Sensor NM140 Series

Shanghai Zanke is a wholesale manufacturer of the temperature sensor NM140 series. At this stage, the main products of Shanghai Zanke Company include flow switches, pressure switches, temperature switches, electromagnetic flowmeters, vortex flowmeters, turbine flowmeters, ultrasonic flowmeters, material (liquid) level flowmeters and other instruments. Application industries: petroleum chemical industry, natural gas, machinery, electric power, metallurgy, building materials, food and pharmaceutical manufacturing, agriculture, environmental protection, etc. (Our company can customize instrument specifications according to users' special requirements and on-site working conditions, and provide installation and commissioning services.)

Well, that's all for today's introduction to the working principle, application fields, characteristics, installation requirements, use and maintenance of the temperature sensor NM140 series. If you have any other questions, please feel free to contact us, and we will reply to you as soon as possible after receiving your inquiry.
