Universal Temperature Transmitter NM121 Series

Product Overview

The NM121 is a temperature transmitter with a wide measurement range. It uses a thermocouple or PT100 thermal resistor for temperature measurement, and the signal is processed by the rear processing circuit and converted into a standard industrial electrical signal output. The all-metal housing design enables this series of products to be used in various industrial occasions. HART output is optional. Users can choose to install an LED or LCD digital display according to their requirements.

Product Features

• Universal product

• Measurement range: -200...1800°C (user-definable)

• 4...20mA output

• Optional HART protocol

• Multiple process connections available

• Optional 4-digit LED/LCD digital display

• All-metal housing

Product Applications

• Circulating water/cooling water

• Iron and steel industry

• Oil and gas industry

• Machinery manufacturing

• Water treatment

• Glass industry

Technical Parameters

• Power supply voltage: 10...30Vdc

• Current consumption: Consistent with the output signal current (4...20mA)

• Measurement range: -200...1800°C (within this range, user-definable)

• Ambient temperature: -20...80°C

• Storage temperature: -30...100°C

• Housing: Die-cast aluminum

• Medium contact part: 316 stainless steel

• Output: 2-wire current-type analog output

• Load RA (ohm): RA ≤ (Us - 10)V / 0.02A

• Linearity: ≤ ±0.5% of full scale

• Sensor: PT100 Class A (PT1000 can be customized)

• Accuracy: ≤ ±0.2% of full scale

• Protection class: IP65

• Outlet mode: Terminal wiring

Wiring Diagram

Connection Schematic Diagram

2-wire type: 1 2 3 4

Zanke NM121 Series

24VDC

1

2

Terminal Wiring

Selection Table
