Pipeline Temperature Sensor NM143 Series

Product Overview

The NM143 series pipeline temperature sensor is a high-precision temperature measurement product independently developed by our company. It is designed with a special structure, which can be directly installed on pipelines or containers for temperature measurement. The product adopts imported high-precision sensitive components, featuring high measurement accuracy, good stability, strong anti-interference ability, and long service life. It is suitable for temperature measurement in various industrial pipelines, heating systems, air conditioning systems, and other occasions.

Product Features

• High precision: Measurement accuracy up to ±0.2℃

• Good stability: Long-term stability ≤0.1℃/year

• Strong anti-interference ability: Effectively resists electromagnetic interference and radio frequency interference

• Easy installation: Can be directly installed on pipelines or containers through threaded connections

• Wide measurement range: -50℃~200℃ (special ranges can be customized)

• Various output signals: Optional 4-20mA, RS485 (Modbus-RTU protocol)

• Durable: Made of high-quality 304 stainless steel material, corrosion-resistant and high-temperature resistant

Product Applications

• Industrial pipelines: Petroleum, chemical, natural gas, water treatment and other industrial pipelines

• Heating systems: Central heating pipelines, floor heating systems, etc.

• Air conditioning systems: Air conditioning water pipelines, air ducts, etc.

• Food and pharmaceutical industry: Production pipelines, storage tanks, etc.

• Environmental protection industry: Sewage treatment pipelines, waste gas treatment equipment, etc.

Technical Parameters

Wiring Diagram

• 4-20mA output wiring (two-wire system):

  Red wire: Power supply positive (12~24VDC+)

  Blue wire: Signal output / power supply negative (connected to the acquisition device input positive)

  Note: The acquisition device input negative is connected to the power supply negative.

• RS485 output wiring (four-wire system):

  Red wire: Power supply positive (12~36VDC+)

  Black wire: Power supply negative (12~36VDC-)

  Yellow wire: RS485 A

  Green wire: RS485 B

  Note: It is recommended to use shielded twisted-pair cables for RS485 communication, and the shield layer should be grounded at one end.

Selection Table

Example: NM143-T-A-G1/2-L100-D8 indicates NM143 series pipeline temperature sensor, with 4-20mA output signal, G1/2" thread, 100mm probe length, and 8mm probe diameter.

Wholesale of Pipeline Temperature Sensor NM143 Series

Shanghai Zanke is a wholesale manufacturer of the pipeline temperature sensor NM143 series. At this stage, the main products of Shanghai Zanke Company include flow switches, pressure switches, temperature switches, electromagnetic flowmeters, vortex flowmeters, turbine flowmeters, ultrasonic flowmeters, material (liquid) level meters and other instruments. Application industries: petroleum chemical industry, natural gas, machinery, electric power, metallurgy, building materials, food and pharmaceutical manufacturing, agriculture, environmental protection, etc. (Our company can customize instrument specifications according to users' special requirements and on-site working conditions, and provide installation and commissioning services.)

Well, that's all for today's introduction to the working principle, application fields, characteristics, installation requirements, use and maintenance of the pipeline temperature sensor NM143 series. If you have any other questions, please feel free to contact us, and we will reply to you as soon as possible after receiving your inquiry.
